p5 Outdoor Stage Video Screen SMD RGB 320*160mm LED Display
1. Using branded LED lamp, drive IC and private design module board
Product Featrues
EPISTAR SMD2727 LED lamp, MBI5124IC and four layer module board in LED module manufacturing processing, with up to 281 trillion display color, 1024 levels grey and up to 100,000 working hours.
2. Reliable working performance
LED screen has highly dependable working performance and much great market acceptance. More excellent user experience is well guaranteed.
3. Fast delivery with product life supports
Production capacity exceeds 1400SQM per month. good quality control, affordable prices, fast delivery and product life supports.
Supply Ability
Supply Ability: 400 Square Meter/Square Meters per Month.
Packaging & Delivery
- Packaging Details
- LED module and accessories hard carton package
Flight case and wooden case package for cabinets.
- Port
- SHENZHEN CHINA
- LOGO
- Acceptable
- Lead Time :
-
| Quantity(Square Meters) | 1 - 100 | >100 |
| Est. Time(days) | 25 | To be negotiated |
-
Product Specification
| Model number | P5 |
| Pixel pitch | 5mm |
| Module resolution | 32 *16 |
| Module size | 320m*160mm |
| Pixel Density | 40000dots/sqm |
| LED encapsolution | SMD3535 |
| Module Weight | 0.4kg |
| Average consumption | 1000w/sqm |
| Max power consumption | 800w/sqm |
| Best View distance | ≥5m |
| Viewing angle | 140º |
| Brightness | ≥6500cd/sqm |
| Scanning | 1/8scan |
| Refresh rate | ≥1920Hz |
| Waterproof | IP65 |
| Grey Scale | 1024 levels |
| Working voltage | 220VAC/50Hz |
| Life span | 100000hours |
| Certification | CCC/CE/RoHS |
Featured Projects
Warranty Terms
ANWELL team could provide dependable pre-sales services, post-sales supports and complete project solutions assistance for every customers.
1. All the products purchased from ANWELL company carries one year free replacements and product life supports.
A: Two years warranty period, including one year free replacement warranty period..
B: Product life supports and free project design.
2. Faulty products includes LED module, power supply, system cards and accessories will be returned to ANWELL factory for maintenance if necessary.
3. Complete project solutions services ranges from project design, installation, operation to future maintenance. Fast response capability to customers' request.
4. 24 hours aging test for every finished products before delivery, no tolerance in faulty products. Top quality will be well guaranteed.
5. Special offers available for preferred clients.
Product Tags:
|
|
High Brightness 1920Hz P5 LED Display Panel Waterproof LED Display Module Images
|
